FRS/BRZ/GT86 Road Race Spec – Non-Gutted X Door Bar Roll Cage

SKU: ZN6-A-2101 – 1.75″ x .095″ Main Structure SKU: ZN6-A-2102 – 1.75″ x .120″ Main Structure Road Race Spec – Made to Order – Ships When Complete Overview The ZN6 Road Race Non-Gutted Roll Cage Kit with X-Style Door Bars is engineered for dedicated track use while maintaining key street-friendly features. Built from 1.75″ x .095″ DOM tubing in the main structure, this kit is designed to meet NASA tech compliance for road racing applications. Built from 1.75″ x .120″ DOM tubing in the main structure, the kit is designed to meet SCCA tech compliance for road racing applications. Supporting bars are constructed from 1.5″ x .095″ DOM tubing, keeping strength high and unnecessary weight low. The non-gutted configuration allows for trimmed factory door panels and functional windows. Key Features Vehicle Fitment: 2012–2020 Scion FR-S / Toyota 86 / Subaru BRZ (Chassis: ZN6 / ZC6) Material Options: Main Structure: 1.75″ x .095″ DOM (NASA Tech Spec) Main Structure: 1.75″ x .120″ DOM (SCCA Tech Spec) Supporting Structure: 1.5″ x .095″ DOM Design and Construction: Weld-in kit – requires welding and chassis prep CNC Notched & Mandrel Bent Tubing for fast, accurate assembly Laser-Etched Fitment Guides for consistent tube alignment X-Style Door Bars for improved accessibility and side impact protection Main structure includes: Main Hoop, Front Top Bar, Rear Down Bars, A-Pillars Supporting structure includes: X Door Bars, Dash Bar, Door Bar Supports, Tube Gussets Non-Gutted Configuration: Requires trimming of OEM door panels Retains functional manual or power windows Ideal for endurance cars or dual-purpose builds Description The ZN6-A-2101 or ZN6-A-2102 Road Race Roll Cage Kit offers serious racers a high-spec solution with the flexibility to retain partial interior comfort and window function. The non-gutted layout allows for a cleaner install in builds that see occasional street time or long track days. All tubing is precision-machined with CNC notches and laser alignment marks to ensure efficient, hassle-free installation. The X door bars provide excellent ingress/egress while still offering significant side impact resistance—perfect for drivers who value practicality without sacrificing performance. Important Notes Made to order – All sales are final Door panel trimming required to clear X door bars Windows remain functional Always verify compliance with your specific sanctioning body rules before ordering Want to see it in action? Check out our Instagram.Need install help? Media tab’s got you.
