Blue Sea ST Blade Fuse Block-6 Circuits by Agile Offroad
$53.99
$89.63
Compact 6 Circuit Fuse Block with Negative Bus and Cover The Blue Sea 6 Circuit ATC Fuse Block provides a clean, organized way to manage accessory power with an integrated negative bus. Designed for reliable 12V systems, it consolidates branch circuits and in-line fuses into a compact, service-friendly solution. Key Features Six ATC or ATO fused circuits Integrated bused ground for simplified wiring Accepts ring or snap fork terminals Tin-plated copper bus and fuse clips Optional protective cover available Meets ABYC and USCG insulation requirements Specifications Circuits: 6 Maximum Amperage: 100A per block, 30A per circuit Maximum Voltage: 32V DC Mounting: #8 screw (M4) Positive Bus: #10-32 stud Negative Bus: #10-32 stud Recommended Torque: 24 in-lb (2.71 Nm) Screw Terminal Torque: 18 in-lb (2.03 Nm) Screw Type: #8-32 with captive star lock washer Weight: 0.55 lb (0.25 kg) Note: Fuses sold separately.
